Memory

256M / 512M / 1G / 2G / 4G / 8G/16G Option

Battery

500-8000 mAh (Rechargeable)

Screen

1.8 inch, 2.4 inch, 2.8 inch, 3.5 inch, 4.3 inch, 5 inch, 7 inch and 10 inch.

Buttons

0-10 buttons (On/Off, Play/Pause and Video Selection etc.)

Paper size

A4, A5 and customization.

Item

Description

Remarks

Video card

Switch

Magnetic switch or ON/OFF button switch

LCD Screen

Screen Size

Pixel Size

Aspect Ratio

2.4’’

320 X 240

4:3

2.8’’

320 X 240

4:3

4.3’’

480 X 272

4:3

5.0’’

480 X 272

16:9

7.0’’

800 X 480

16:9

10’’

1024 X 600

16:9

Function Control Buttons (Available If Required)

ON/OFF button

1

When adding buttons to the artwork, the centre of each button need to be at least 15mm from
The edge of the screen, the edge of the card,
Or another button

Volume Up

1

Volume Down

1

Video Files

0-8

Play/Pause

1

Print Size

A4, A5, DL (12.7 X 17.7 cm)

Customized print sizes are accepted.

Print Solution

Please ensure all images are supplied in CMYK not RGB.

Number of Video Files

1-8

Memory

128 MB to 8 GB

Battery

Rechargeable battery

Lifespan

1.5h-3h

Video card

Mini USB Port and cable

1 USB port for uploading files and charging

Screen Placement

The screen outline can be moved within the boundary of the card, but must be at least 15mm clear of the edge of the card, the buttons and the USB port.
